Checking wiring and terminals
- Ignition off.
Check the brake control module connector. Check for damaged or bent terminal pins. Check for contact resistance and oxidation.
Check the wiring for CAN communication between terminals #A11 (#A11) and #B13 (#B13) and between terminal #15 (#A15) and #B1 (#B11). Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage.
Check that the wiring is not too close to a source of interference such as a carphone etc.
Remedy as necessary.
Other information
- To check the wiring and connections, see Contents .
- Continue
Refer to Verification
