2004 Volvo V40 BaseFACTORY OEM SERVICE PROCEDURE

Checking the control module connection: Verification

HINT: After carrying out the repair, check that the fault has been remedied as follows:

Fig 1: Identifying Ignition ON

Courtesy of VOLVO CARS OF NORTH AMERICA.

Ignition off.
Reinstall the connectors, components etc.
Ignition on.
The ABS warning lamp must light when the ignition is switched to position II. It should go out after 4 seconds, or when the engine is started.

HINT: The ABS warning lamp does not go out if the control module has registered a fault.

Fig 2: Checking Freewheel Function (Poly V-Belt Removed)
Courtesy of VOLVO CARS OF NORTH AMERICA.

Does the lamp go out approximately 4 seconds after the ignition is switched on?

YES
VERIFIED: Troubleshooting has been completed.
NO
Refer to Information
