2004 Nissan-Datsun Sentra SE-RFACTORY OEM SERVICE PROCEDURE
Component Locations
WARNING: This page is about a different car, the 2002 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.
COMPONENT LOCATIONS
| Component | Location |
|---|---|
| ECM | Behind Center Console, See Fig 1 |
| Fuel Tank Gauge Unit | Under Left Rear Seat, See Fig 2 |
| Fuse Block (J/B) | Behind Left Side Of Dash, See Fig 3 |
| Fuse & Fusible Link Box | Under Hood, In Front Of Right Strut Pillar, See Fig 4 |
| Key Switch | On Steering Column, Under Steering Column Covers, See Fig 5 |
| Left Front Door Switch | On Bottom Of Left Front Door Post, See Fig 6 |
| Seat Belt Buckle | On Right Side Of Front Seat, See Fig 7 |
| Smart Entrance Control Unit | Behind Left Side Of Dash, See Fig 8 |
| Thermal Transmitter | On Thermostat Housing, See Fig 9 |
