2011 Ford Mustang V8-5.4L SCFACTORY OEM SERVICE PROCEDURE
Engine Control Module: Service and Repair
Powertrain Control Module (PCM)
Removal
1. Retrieve the module configuration. Carry out the module configuration retrieval steps of the Programmable Module Installation (PMI) procedure. For additional information, refer to Module Configuration Programmable Module Installation (PMI).
2. Remove the 8 retainers and the radiator sight shield.
3. Disconnect the 3 PCM electrical connectors.
4. Remove the 2 bolts and the PCM.
Installation
1. Install the PCM and the 2 bolts.
- Tighten to 8 Nm (71 lb-in).
2. Connect the 3 PCM electrical connectors.
3. Install the radiator sight shield and the 8 retainers.
4. Restore the module configuration. Carry out the module configuration restore steps of the Programmable Module Installation (PMI) procedure. For additional information, refer to Module Configuration Programmable Module Installation (PMI).
5. After completing the repairs, use the scan tool to perform the Misfire Monitor Neutral Profile Correction procedure, following the on-screen instructions.
