Body Side
Explanation of symbols
As measured from center
As measured from one edge
As measured from cut marking
As measured from the bottom of the recess. If only one measurement point symbol is shown, it applies to both points. Otherwise, the symbols appear on each side of the measurement designation in the graphic.
