Read input and output signals (MODE 5): General
This test mode displays the last reason the cruise control was disengaged.
This test mode can be used when the cruise control has been disengaged even though the driver has not activated any of the system's components. The code stored will only remain in the memory until the ignition is turned off or the next time the cruise control is disengaged.
Note that the code is not identified as a diagnostic trouble code (DTC) because a code is stored even when the system is disengaged normally, for example when braking.
If the engine is turned off after a test drive the response code 2-1-4 will always be posted when the ignition is turned on even if there is no actual fault.
The following reasons for cruise control disengagement give these codes:
- safety disengagement
- gear selector in P or N
- selector switch is set to OFF
- brake valve activated
- clutch valve activated
- brake light switch activated
- supply voltage too low.
