2003 Toyota PriusFACTORY OEM SERVICE PROCEDURE
Remove Blower Motor Control
- Using a drill, drill out the 2 rivet heads and remove the blower motor control.
- Gently and vertically put the drill to the rivet, and cut the rivet flanges.NOTE:
- Prizing the hole with a drill can lead to damage to the rivet hole or breaking the drill.
- Take cafe as the cut rivet is hot.
- Using a vacuum cleaner, remove the drilled rivet and their dust.
