1990 Toyota Corolla Base, AutomaticFACTORY OEM SERVICE PROCEDURE
Cold Start Injector Test
- Cold start injector and cold start injector time switch are both fed current from ignition switch during cranking. Cold start injector ground circuit is controlled by cold start injector time switch. To test cold start injector, unplug cold start injector wiring harness. Check resistance between terminals of injector. Resistance should be 3-5 ohms. Replace injector if defective.
- To check cold start injector spray pattern and leakage, relieve fuel system pressure. Remove cold start injector from vehicle.
- Install fuel hose to injector. If original hose is too short, use Fuel Injection Kit (09268-41045) to extend the hose length and add a union. See Fig 2.
- Place container under cold start injector. Turn ignition on, with engine off. Connect jumper wire to engine check connector terminals "FP" and "+B" to pressurize fuel system. For engine check connector location, see Figure. Fuel pump check connector is 2-wire connector near airflow meter in left rear corner of engine compartment (White/Black and Green wires).
