1988 Toyota 4Runner Base, AutomaticFACTORY OEM SERVICE PROCEDURE
Land Cruiser
- Raise one rear wheel off the ground and secure vehicle. Release parking brake and place transmission in Neutral. Disconnect wiring connector from EFI ECU, located behind glove box.
- Attach ohmmeter positive lead to connector terminal and negative lead to ground. See Fig 1. Turn rear wheel and monitor ohmmeter. Ohmmeter needle should deflect consistently.
- If ohmmeter does not deflect, check that speed sensor terminals at rear of speedometer are properly connected. If connection is okay, replace speedometer assembly.
