1996 Suzuki Swift AutomaticFACTORY OEM SERVICE PROCEDURE
TP Sensor Adjustment
- With voltage measurement equipment still in place, insert 0.14" (3.5 mm) feeler gauge between throttle stop and throttle lever. Ensure ISC plunger is not contacting throttle lever screw.
- Loosen TP sensor screws and rotate back and forth until 0.98-1.02 volts is obtained. Tighten TP sensor screws to 14-21 INCH lbs. (1.6-2.4 N.m).
THROTTLE POSITION (TP) SENSOR VOLTAGE (1)
| Application | Volts | ||||
|---|---|---|---|---|---|
| Swift (2) | |||||
| With 0.140" (3.5 mm) Clearance At Stop Screw | 0.98-1.02 | ||||
|
|||||
