1988 Suzuki Samurai BaseFACTORY OEM SERVICE PROCEDURE
Power Circuits
- Ignition coil, solenoids and/or solenoids valves are connected to ECM. If any component(s) is disconnected or fails, a signal will not be sent to ECM. As a result, feedback will NOT operate properly. To check power circuits, disconnect ECM connector at ECM.
- Turn ignition on without starting engine. Attach a voltmeter between terminal No. 2 (wire harness side) and a good ground. See Fig 1 . Voltage should be approximately 12 volts. Repeat procedure for terminals No. 3, 8, 9, 12, 13, 16, and 18.
- If any circuit is not approximately 12 volts, repair wire and/or replace component as necessary.
