RH Side
- Install the knock sensor to the cylinder block.NOTE: The knock sensor should be installed so that the center of the connector is positioned at a 32.5 - 47.5° angle relative to the rear of engine.
Tightening torque:
24 N.m (2.4 kgf-m, 17.7 ft-lb)
- Connect the connector to the knock sensor.
- Install the fuel pipe insulator No. 3. Refer to FUEL INJECTION (FUEL SYSTEMS) (W/O STI)>FUEL INSULATOR>INSTALLATION>FUEL PIPE INSULATOR NO. 3 .
- Install the intake manifold. Refer to FUEL INJECTION (FUEL SYSTEMS) (W/O STI)>INTAKE MANIFOLD>INSTALLATION .
- Connect the ground terminal to battery sensor. Refer to NOTE>NOTE>BATTERY .
- Install the collector cover. Refer to INTAKE (INDUCTION) (W/O STI)>COLLECTOR COVER>INSTALLATION .
