Knock Sensor: Installation
- Install the knock sensor to the cylinder block.NOTE: The knock sensor should be installed so that the center of the connector is positioned at a 76.5 - 91.5° angle relative to the front of engine.
Tightening torque:
24 N.m (2.4 kgf-m, 17.7 ft-lb)
- Connect the connector to the knock sensor.
- Install the air intake boot. Ref. to INSTALLATION , Air Intake Boot.
- Connect the battery ground terminal.
