2012 Subaru Outback Base, Standard TransFACTORY OEM SERVICE PROCEDURE
Model With Electric Retractable Mirror
CAUTION:
- When removing the mirror, be careful not to damage the back surface of mirror with a flat tip screwdriver.
- When installing the mirror, insert the connector and clip securely.
- Operate the remote control mirror switch to face the mirror surface upward.
- Disconnect the ground cable from battery.
- Remove the outer mirror.
- Using a flat tip screwdriver, release the clips then remove the outer mirror by sliding downward.
- Disconnect the mirror heater connector. (Model with mirror heater)
- Install the outer mirror in the reverse order of removal.
