2001 Subaru Forester BaseFACTORY OEM SERVICE PROCEDURE

Oil Pump Assembly: Disassembly

Remove the oil seal retainer.
Also remove the O-ring and oil seal (air breather).

Fig 1: Removing Oil Seal Retainer
Remove O-rings from oil pump housing.
CAUTION: Be careful not to damage O-ring.
Remove the four seal rings.
CAUTION: Be careful not to damage seal ring.
