2006 Saturn Ion Red LineFACTORY OEM SERVICE PROCEDURE

Removal Procedure

Fig 1: Identifying Steering Column Filler Panel

Courtesy of GENERAL MOTORS CORP.

Remove the steering column filler panel. Steering Column Filler Replacement .
Disconnect the instrument panel (I/P) wiring harness electrical connector from the accelerator pedal position (APP) sensor.

Fig 2: View Of Accelerator Pedal Position Assembly
Courtesy of GENERAL MOTORS CORP.
Remove the accelerator pedal bolts.
Remove the accelerator pedal with sensor.
