Removal Procedure
- Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnect/Connect Procedure in Engine Electrical.
- Raise the vehicle on a hoist until the tires are off the ground. Refer toLifting and Jacking the Vehicle in General Information.
- Remove the right front tire. Refer toTire and Wheel Removal and Installation in Tires and Wheels.
- Remove the inner right side splash shield to gain access to the crankshaft pulley. Refer to Splash Shield Replacement - Engine in Body Front End.
- Remove the #4 ignition coil and spark plug.
- Rotate the engine to bring the cylinder #4 to top dead center (TDC) compression stroke.
The crankshaft pulley-timing notch should be aligned with the timing mark on the front cover.
