2003 Saab 9-3 Vector, AutomaticFACTORY OEM SERVICE PROCEDURE

Control module outputs

Fig 1: Identifying Control Module Outputs Components

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Wheel speed, FR (430).
Wheel speed, RL (540).
Return pump (547).
ABS warning lamp on MIU (540).
Data link (445).
Wheel speed, FL (430/505/589/595).

Fig 2: Identifying Control Module Outputs Components
Courtesy of SAAB-SCANIA OF AMERICA, INC.
Inlet valve, FL (547).
Outlet valve, FL (547).
Inlet valve, RR (547).
Outlet valve, FR (547).
Inlet valve, RL (547).
Outlet valve, RL (547).
Inlet valve, RR (547).
Outlet valve, RR (547).
