1990 Plymouth Colt BaseFACTORY OEM SERVICE PROCEDURE
Power Transistor (Fuel Injected Models)
- Disconnect power transistor connectors. Using a DVOM, connect positive ohmmeter lead to terminal No. 2 and negative lead to terminal No. 3. See Fig 3 . Ensure there is no continuity.
- Using a 1.5-volt dry cell battery, connect positive end of 1.5-volt battery to power transistor terminal No. 1 and negative end to terminal No. 2. DVOM should now read continuity at power transistor terminals No. 2 and No. 3. If DVOM does not respond as described, replace power transistor.
