1997 Oldsmobile RegencyFACTORY OEM SERVICE PROCEDURE
Torque Specifications
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |||
|---|---|---|---|---|
| Column Bracket-To-Instrument | ||||
| Panel Stud Nuts | 20 (27) | |||
| Column Bracket-To-Upper Support Bolts | 20 (27) | |||
| Flexible Coupling Nuts | 20 (27) | |||
| Intermediate Shaft-To-Steering | ||||
| Shaft Bolt | 35 (47) | |||
| Lower Intermediate | ||||
| Shaft-To-Steering Gear Box Bolt | 35 (47) | |||
| Steering Wheel Nut | 30 (41) | |||
| Steering Wheel Rotation Sensor | 40 (54) | |||
| Upper Intermediate | ||||
| Shaft-To-Steering Column Bolt | 40 (54) | |||
| INCH Lbs. (N.m) | ||||
| Air Bag Module Screws | 27 (3.0) | |||
| Dimmer Switch Nut & Stud | 35 (4) | |||
| Ignition Switch Screw & Stud | 35 (4) | |||
| Lock Cylinder Screws | 22 (2.5) | |||
| Lock Housing Cover Screws | 80 (9) | |||
| Support-To-Jacket Screws | (1) 77 (8.8) | |||
| Turn Signal Switch Screws | 30 (3.4) | |||
|
||||
