2020 Nissan-Datsun GT-R Track EditionFACTORY OEM SERVICE PROCEDURE
ID Registration Without Transmitter Activation Tool
- Decrease air pressure for at least 30 seconds continuously for each tire (more than 10 psi (34.5 kPa) within 30 seconds) to place the TPM system into relearn mode for 30 minutes.
- Adjust the tire pressure for all wheels as indicated in the Sensor ID Registration Tire Pressure Specifications table.Sensor ID Registration Tire Pressure Specifications
Tire Position Tire Pressure - psi (kPa) Front Left 25 (172) Front Right 40 (276) Rear Right 60 (414) Rear Left 80 (551) - Start the Registration procedure using the INFO knob as follows: SETTINGS ->RESET TPMS ->RELEARN ->RESETTING. The TPMS warning lamp flashes continuously when the system is relearning the tire positions. See Fig 1.NOTE: If the Registration procedure is stopped before completion, the new tire positions are not learned. Perform the complete relearn procedure again to reset the tire positions.
- When the Registration procedure is successfully completed the TPMS warning lamp illuminates for 3 seconds and a chime sounds 3 times.
- Adjust the tire pressures to the cold tire pressure specification. If the tire pressures are correct, the TPMS warning lamp turns OFF.
