2017 Nissan-Datsun Sentra SLFACTORY OEM SERVICE PROCEDURE
Body Compartment
WARNING: This page is about a different variant/trim than selected.
| 1. | A/C auto amp. | 2. | Combination meter | 3. | BCM |
| 4. | ASCD steering switch | 5. | EPS control unit | 6. | EVAP control system pressure sensor |
| 7. | EVAP canister vent control valve | 8. | EVAP canister | 9. | Fuel level sensor unit and fuel pump |
| 10. | Fuel tank temperature sensor | 11. | G sensor | 12. | Cooling fan control module |
| 13. | Cooling fan motor | 14. | Clutch pedal position switch | 15. | Brake pedal position switch |
| 16. | Stop lamp switch | 17. | Accelerator pedal position switch | 18. | Brake pedal position switch |
| 19. | Stop lamp switch | 20. | Accelerator pedal position switch | ||
| A. | Right rear undercarriage area | B. | Inside fuel tank | C. | Under driver seat |
| D. | Front side of engine | E. | Periphery of pedals (M/T models) | F. | Periphery of pedals (CVT models) |
| : Vehicle front |
