2015 Nissan-Datsun Sentra SRFACTORY OEM SERVICE PROCEDURE
Engine Compartment
| Engine front side |
| No. | Component | Function |
|---|---|---|
| PCV valve | The positive crankcase ventilation (PCV) valve is provided to conduct crankcase blow-by gas to the intake manifold. | |
| Fuel injector | FUEL INJECTOR | |
| Knock sensor | KNOCK SENSOR | |
| Engine oil temperature sensor | ENGINE OIL TEMPERATURE SENSOR | |
| Crankshaft position sensor (POS) | CRANKSHAFT POSITION SENSOR (POS) | |
| Engine oil pressure sensor | ENGINE OIL PRESSURE SENSOR | |
| Engine coolant temperature sensor | ENGINE COOLANT TEMPERATURE SENSOR | |
| Camshaft position sensor (PHASE) | CAMSHAFT POSITION SENSOR (PHASE) | |
| Exhaust valve timing control position sensor | EXHAUST VALVE TIMING CONTROL POSITION SENSOR | |
| Ignition coil (with power transistor) |
IGNITION COIL WITH POWER TRANSISTOR | |
| Exhaust valve timing control solenoid valve | EXHAUST VALVE TIMING CONTROL SOLENOID VALVE | |
| Intake valve timing control solenoid valve | INTAKE VALVE TIMING CONTROL SOLENOID VALVE |
