2004 Nissan-Datsun Sentra SE-RFACTORY OEM SERVICE PROCEDURE
Component Locations
WARNING: This page is about a different car, the 2003 Nissan Pathfinder and 2002 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.
COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Defogger Negative Connector | Top Right Of Rear Window, See Fig 1 |
| Defogger Positive Connector | Top Left Of Rear Window, See Fig 2 |
| Defogger Relay | In Fuse Box No. 1, See Fig 3 |
| Defogger Switch 2002 Model (2003 Model With Auto A/C Without NAVI) | Left Side Of Instrument Panel, Under Hazard Switch, See Fig 4 |
| Defogger Switch 2003 Model (With Auto A/C & NAVI & With Manual A/C) | In Center Console, Next To Temperature Control Knob, See Fig 5 |
| Fuse Block (J/B) | Behind Left Side Of Dash, See Fig 6 |
| Fuse & Fusible Link Box | Under Hood, In Front Of Right Strut Pillar, See Fig 7 |
| Smart Entrance Control Unit | Behind Left Side Of Dash, See Fig 8 |
