WARNING: This page is about a different car, the 2003 Lexus ES 300 and 2002 Lexus ES 300. However, it is still accessible from the selected car via links, so may be relevant.

COMPONENT LOCATIONS

Component

Location

ABS & Traction Actuator Assembly

⁽¹⁾

A/C Control Assembly

⁽²⁾

Door Courtesy Light Switch

⁽¹⁾

Driver Side Junction Block

⁽²⁾

Engine Control Module (ECM)

⁽²⁾

Engine Oil Pressure Switch Assembly

⁽³⁾

Engine Room Junction Block

⁽¹⁾

Front Seat Inner Belt Assembly

⁽²⁾

Fuel Sender Gauge Assembly

⁽¹⁾

Instrument Panel Assembly

⁽¹⁾

Instrument Panel Components

⁽⁴⁾⁽⁵⁾

Light Control Rheostat

⁽²⁾

Light Failure Indicator Sensor

⁽¹⁾

Occupant Detection Sensor

⁽²⁾

Park/Neutral Start Switch

⁽¹⁾

Passenger Side Junction Block

⁽²⁾

Skid Control ECU Assembly W/ VSC

⁽²⁾

Steering Pad Switch

⁽²⁾

Turn Signal Flasher Relay

⁽²⁾

Unlock Warning Switch Assembly

⁽²⁾

Water Temperature Sensor

⁽³⁾

⁽¹⁾	See Fig 1.

⁽²⁾	See Fig 2.

⁽³⁾	See Fig 3.

⁽⁴⁾	See Fig 4.

⁽⁵⁾	See Fig 5.

Fig 1: Identifying Instrument Panel Outer Component Locations
