CKP sensor is located inside distributor. If a fault is present in CKP sensor, Code 11 may be set in ECM memory. If Code 11 is set, perform appropriate CODE 11 (CKP SENSOR) in appropriate G - TESTS W/ CODES article in the ENGINE PERFORMANCE section below.
- TESTS W/CODES - 1.6L
- TESTS W/CODES - 2.0L
To test CKP sensor, remove distributor. Leave wiring harness connected. Using a voltmeter, connect negative lead to ground and alternately connect positive lead to 1-degree signal terminal and 120/180-degree signal terminal. See CKP SENSOR INPUT SIGNAL TERMINALS table. See Fig 1 and Fig 2 .
Measure voltages at both terminals while rotating distributor by hand. Voltage should fluctuate 0-5 volts. If either voltage signal does not fluctuate 0-5 volts, check harness for short or open circuit. If no problems are found, replace CKP sensor.

CKP SENSOR INPUT SIGNAL TERMINALS

Application	1-Degree Signal	120/180-Degree Signal
1.6L	Terminal No. 2	Terminal No. 1
2.0L	Terminal "D"	Terminal "A"

Fig 1: Distributor Wiring Harness Connector Terminal ID (1.6L)

Courtesy of NISSAN MOTOR CO., U.S.A.
