1993 Nissan-Datsun Sentra SE-R, StandardFACTORY OEM SERVICE PROCEDURE
Auxiliary Air Control (AAC) Valve Test (Maxima VG30E)
Check resistance between terminals No. 1 and 2; 2 and 3; 4 and 5; and 5 and 6 of AAC valve connector. See Fig 1 . If resistance is not 27-40 ohms at 68°F (20°C), replace AAC valve.
