Vehicle Information Code Plate: Notes
The vehicle information code plate is riveted onto the engine hood in the engine compartment.
The plate shows model code, engine model, transaxle model and body color code.
| NO. | ITEM | CONTENT | |
|---|---|---|---|
| 1 | MODEL | CT9ASNGF ZL2M | CT9AS: Vehicle model |
| NGFZL2M: Model series | |||
| 2 | ENGINE | 4G63 | Engine model |
| 3 | EXT | ZZZ | Exterior code |
| 4 | TRANS AXLE | W5M51 | Transaxle model |
| 5 | COLOR | W83 | Body color code |
| 6 | INT | 33X | Interior code |
| 7 | OPT | N22 | Equipment code |
For monotone color vehicles, the body color code shall be indicated.
