Injector Coil: Notes
Set ignition switch to "OFF" position. Disconnect connectors from injectors. Check injector coil for continuity with circuit tester. Resistance should read 2-3 ohms. If resistance is zero ohms or abnormally large, a short or open circuit exists in coil. Replace injector and reconnect connectors to injectors.
