2005 Mercury Mariner 3.0 1, FWDFACTORY OEM SERVICE PROCEDURE
Occupant Classification Sensor (OCS) Module Connector End View (C3285)
C3285 CONNECTOR SPECIFICATION
| Pin | Circuit | Gauge | Circuit Function | Qualifier |
|---|---|---|---|---|
| 1 | 937 (RD-WH) | 20 | Voltage supplied in Start and Run (overload protected) | |
| 2 | * | * | not used | |
| 3 | 1568 (RD-WH) | 20 | Seat pressure sensor, input | |
| 4 | 1570 (TN-BK) | 20 | Seat pressure sensor, output | |
| 5 | 1569 (GY-LB) | 20 | Seat pressure sensor, signal return | |
| 6 | * | * | not used | |
| 7 | * | * | not used | |
| 8 | * | * | not used | |
| 9 | 1919 (PK-OG) | 20 | High speed CAN bus - | |
| 10 | * | * | not used | |
| 11 | 2088 (TN-RD) | 20 | Seat belt tensioner, passenger seat, feed | |
| 12 | 2089 (OG-BK) | 20 | Seat belt tensioner, passenger seat, signal | |
| 13 | 1203 (BK-LB) | 20 | Ground | |
| 14 | 1203 (BK-LB) | 20 | Ground | |
| 15 | * | * | not used | |
| 16 | * | * | not used | |
| 17 | * | * | not used | |
| 18 | 1918 (BR-WH) | 20 | High speed CAN bus + |
