Compression Pressure
Maximum variation between cylinders is 20 lbs. (all engines) .
| 289" | 130-170 lbs. |
| 390" | 160-200 lbs. |
| 410", 428" | 170-210 lbs. |
| All Except 428" Police | (1) Hydraulic | |||||
| 423" Police (Cold) | .028" Int. & Exh. | |||||
| (Hot) | (2).025" Int. & Exh. | |||||
|
||||||
| 289" | 18" at idle |
| 428" Police | 16" at idle |
| All Others | 17" at idle |
