2003 Mazda MPV ESFACTORY OEM SERVICE PROCEDURE
Intake Air Temperature Sensor
INTAKE AIR TEMPERATURE (IAT) SENSOR RESISTANCE (EXCEPT B2300, B3000, B4000 & TRIBUTE)
| Temperature - °F (°C) | Ohms | |||||
|---|---|---|---|---|---|---|
| Mazda6 (1) | ||||||
| -4 (-20) | 13,600-18,400 | |||||
| 68 (20) | 2210-2690 | |||||
| 140 (60) | 493-667 | |||||
| Miata | ||||||
| 68 (20) | 2210-2690 | |||||
| 176 (80) | 290-354 | |||||
| MPV (2) | ||||||
| 50 (10) | 3300-4100 | |||||
| 68 (20) | 2200-2700 | |||||
| 86 (30) | 1400-1900 | |||||
| Protege | ||||||
| 68 (20) | 2000-2900 | |||||
| 176 (80) | 270-370 | |||||
|
||||||
