1984 Mazda B2000 Base, AutomaticFACTORY OEM SERVICE PROCEDURE
Torque Specifications
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| GLC & 626 | ||
| Steering Universal Joints | 13-20 (18-28) | |
| Column Brackets | 12-17 (16-23) | |
| Steering Wheel | 29-36 (40-50) | |
| Tilt Lever Bolt (626 Only) | 13-20 (18-28) | |
| Pickups | ||
| Steering Universal Joint | 13-20 (18-28) | |
| Column Bracket | 12-19 (16-27) | |
| Steering Wheel | 22-29 (30-40) | |
