1978 MG MidgetFACTORY OEM SERVICE PROCEDURE
Exhaust Gas RECIRCULATION: Maintenance
- Remove EGR valve and clean base of valve with a wire brush. Using a spark plug cleaner, clean valve seat and metering valve by holding the diaphragm upward. Blast valve at 30 second intervals until clean.
- Remove all traces of carbon and cleaning compound (from spark plug cleaner) using compressed air. Inspect ports in manifold for carbon build-up. Light deposits are acceptable.
- If heavy deposits have accumulated, the manifold must be removed for cleaning. Install EGR valve and bring engine to normal operating temperature. Repeat EGR test.
