Confirmation Driving Pattern
- Connect the hand-held tester to the DLC3.
- Switch the hand-held tester from normal mode to check mode (see CHECK MODE PROCEDURE ).
- Start the engine and warm up the engine until engine coolant temperature is more than 75°C.
- Drive the vehicle at 38 mph (60 km/h) or more for 40 seconds or more.
- Let the engine idle for 10 seconds or more.
- Perform steps d and e 12 times.
HINT:
If a malfunction exists, the MIL will be illuminated during step f.
