1993 Lexus SC 400FACTORY OEM SERVICE PROCEDURE
Circuit Breaker Operation Test
- Unplug power window switch connector. Using fused jumper wire, connect battery voltage to switch connector terminal No. 5. Connect jumper wire from switch connector terminal No. 1 to ground. See Figure. Raise window to fully closed position. Continue to apply voltage. Ensure there is circuit breaker operation within 4-40 seconds.
- Reverse jumper jumper wires. Window should begin to go down within 60 seconds. Replace motor assembly if operation is not as specified.
