1991 Lexus LS 400FACTORY OEM SERVICE PROCEDURE
Wheel Alignment Specifications
WHEEL ALIGNMENT SPECIFICATIONS (ES250)
| Application | Preferred | Range | ||||
|---|---|---|---|---|---|---|
| ES250 | ||||||
| Camber (1) | ||||||
| Front | 13/32 | -11/32 to 15/32 | ||||
| Rear | -21/32 | -11 3/32 to 3/32 | ||||
| Caster (1) | 1 19/32 | 27/32 to 2 13/32 | ||||
| Steering Axis Inclination (1) | 12 15/16 | N/A | ||||
| Toe-In | ||||||
| Front | 1/32 (.8) | -1/32 to 1/8 (-.8 to 3) | ||||
| Rear | 5/32 | 3/32 to 1/4 (2 to 6) | ||||
| Toe-Out On Turns (1) | ||||||
| Inner | 35 3/4 | N/A | ||||
| Outer | 29 3/4 | N/A | ||||
|
||||||
