2014 Kia Optima SX TurboFACTORY OEM SERVICE PROCEDURE

Manifold Absolute Pressure Sensor (MAPS): Specification

VOLTAGE SPECIFICATION CHART

Pressure (kPa (kgf/cm2 , psi)) Output Voltage (V)
32.5 (0.33, 4.71) 0.5
284.0 (2.90, 41.20) 4.5
Fig 1: Identifying Outer Mirror Lower Cover Hole
G00525115
