2012 Kia Optima SXFACTORY OEM SERVICE PROCEDURE
Connector C
WARNING: This page is about a different variant/trim than selected.
| No | Terminal Description | Condition | Specified Condition |
|---|---|---|---|
| C1 | RR+ | Speaker Output | |
| C2 | RL+ | Speaker Output | |
| C3 | FR TWT+ | Speaker Output | |
| C4 | FL TWT+ | Speaker Output | |
| C5 | FR+ | Speaker Output | |
| C6 | FL+ | Speaker Output | |
| C7 | RR- | Speaker Output | |
| C8 | RL- | Speaker Output | |
| C9 | FR TWT- | Speaker Output | |
| C10 | FL TWT- | Speaker Output | |
| C11 | FR- | Speaker Output | |
| C12 | FL- | Speaker Output |
