2003 Kia Spectra LS, AutomaticFACTORY OEM SERVICE PROCEDURE
Fuel Tank: Installation
WARNING:
Fuel is explosive. An empty fuel tank can still contain explosive gases. Supply adequate ventilation to the work area. Do not smoke and keep sparks and open flames away. Purge fumes from the tank as soon as possible.
- Raise vehicle.
- Remove protective caps from fuel tank ports.
- Place fuel tank on lifting device and carefully raise fuel tank assembly into correct position.
- Reconnect joint hose to fuel tank and tighten clamp.
- Reconnect two fuel hoses to fuel tank.NOTE: Push evaporative hose onto fuel tank fitting at least 1.0 inch (25 mm). Push fuel filler hoses onto fuel tank and filler pipes at least 1.4 inches (35 mm).
