2021 Jeep Cherokee TrailhawkFACTORY OEM SERVICE PROCEDURE
Outlet, Power, Universal Serial Bus: Installation
- Insert the media hub into the floor console end cap.
- Securely engage the plastic retaining tabs (1).
- Install the floor console end cap. Refer to INSTALLATION .
- Connect the negative battery cable. If equipped with an Intelligent Battery Sensor (IBS), connect the IBS connector to the negative battery cable.
