1993 Isuzu Stylus AutomaticFACTORY OEM SERVICE PROCEDURE
Electronic Spark Timing (EST)
- To check system operation, check timing at 1500 RPM with ALDL ungrounded. Locate ALDL connector.
- ALDL is located behind right side of instrument panel. See Fig 1 .
- Install jumper wire between terminals No. 1 and 3 of ALDL connector. See Fig 1 . Note timing at 1500 RPM. If timing changes, system is operating correctly.
