2009 Infiniti QX56 AWDFACTORY OEM SERVICE PROCEDURE

Intake Valve Timing Control Solenoid Valve (RH): Removal

Remove drive belt. Refer to "REMOVAL AND INSTALLATION ".
Disconnect Intake valve timing control solenoid valve connector (RH).
Remove Intake valve timing control solenoid valve (RH) (3) from Intake valve timing control solenoid valve cover (RH) (1).

Fig 1: Identifying Intake Valve Timing Control Solenoid Valve And Cover (RH)
Courtesy of NISSAN MOTOR CO., U.S.A.
