2003 Infiniti M45FACTORY OEM SERVICE PROCEDURE

Control Valve Assembly: Removal

Disconnect the negative battery terminal.
Drain ATF through drain plug.
Disconnect heated oxygen sensor 2 harness connector.
Remove oil pan and oil pan gasket.

Fig 1: Control Valve Assembly Removal Procedure (1 Of 11)
Courtesy of NISSAN MOTOR CO., U.S.A.

CAUTION: Be careful not to damage connector.
