2012 Honda Insight BaseFACTORY OEM SERVICE PROCEDURE
Ignition Coil and Spark Plug Removal/Installation
- Remove the cowl cover and the under-cowl panel (see COWL COVER REPLACEMENT ).
- Remove the engine cover (see step 1 on REMOVAL ).
- Disconnect the ignition coil connectors, then remove the intake side ignition coils (A) and the exhaust side ignition coils (B).
- Remove the spark plugs and inspect them (see SPARK PLUG INSPECTION ).
- Apply a small amount of anti-seize compound to the plug threads, and screw the plugs into the cylinder head, finger tight, then tighten the plugs to the specified torque.
Specified Torque:
18 N.m (1.8 kgf.m, 13 lbf.ft)
- Install the ignition coils in the reverse order of removal.
