Rear Differential Clutch Control Module Programming and Setup (Lambda 14)
If the Rear Differential Clutch Control Module is replaced, the following procedures must be performed:
- Rear Differential Clutch Control Module Programming-Refer to Service Programming System (SPS) .
- Install a scan tool.
- Turn ON the ignition, with the engine OFF.
- Select Clutch Control Module/Rear Drive System Matching Identification Setup in the Rear Differential Clutch Control Module Configuration/Reset Function List.
- Follow the scan tool directions to complete the calibration procedure.
