DELCO-REMY Window: Overhaul: Inspection
Wash all parts in cleaning solvent, except cap, rotor, condenser, breaker plate assembly and vacuum control unit. Degreasing agents may damage insulation of these parts. Inspect breaker plate assembly for damage or wear. Inspect shaft for wear and its fit in bushings in distributor body. If shaft or bushings are worn, they should be replaced. Mount shaft in "V" blocks and check alignment with a dial indicator. Run out should not exceed 0.002". Inspect advance weights for wear or burrs and free fit on their pivot pins. Inspect cam for wear or roughness. Then check its fit on end of shaft. It should be free without any roughness.
