2007 Ford Edge FWD V6-3.5LFACTORY OEM SERVICE PROCEDURE
Cruise Control Switch: Service and Repair
SPEED CONTROL SWITCH
Removal and Installation
MKX
1. Remove the driver air bag module.
2. Remove the 4 screws and the steering wheel control bezel.
All vehicles
3. Remove the speed control switch by pulling the switch toward the rear of the vehicle.
- Disconnect the electrical connector.
4. To install, reverse the removal procedure.
Edge:
MKX:
Removal and Installation
MKX
1. Remove the driver air bag module.
2. Remove the 4 screws and the steering wheel control bezel.
All vehicles
3. Remove the speed control switch by pulling the switch toward the rear of the vehicle.
- Disconnect the electrical connector.
4. To install, reverse the removal procedure.
