1994 Ford Cab & Chassis 7.5 G, 4WD, AutomaticFACTORY OEM SERVICE PROCEDURE
Alignment Specifications
WHEEL ALIGNMENT SPECIFICATIONS
| Application | Preferred | Range | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| F150/250 (2WD) (3) | |||||||||||
| Camber (1) | 0.25 | -0.75 To 1.25 | |||||||||
| Caster (1) | 4 | 2 To 6 | |||||||||
| Toe-In (2) | 0.03 | -0.08 To 0.15 | |||||||||
| Toe-In (1) | 0.06 | -0.16 To 0.3 | |||||||||
| F150 (4WD) (3) | |||||||||||
| Camber (1) | 0.25 | -0.75 To 1.25 | |||||||||
| Caster (1) | 4 | 2 To 6 | |||||||||
| Toe-In (2) | 0.03 | -0.08 To 0.15 | |||||||||
| Toe-In (1) | 0.06 | -0.16 To 0.3 | |||||||||
| F250 (4WD) | |||||||||||
| Camber (1) | 0.25 | -0.75 To 1.25 | |||||||||
| Caster (1) | 4 | 2 To 6 | |||||||||
| Toe-In (2) | 0.03 | -0.08 To 0.15 | |||||||||
| Toe-In (1) | 0.06 | -0.16 To 0.3 | |||||||||
| F350 (2WD) | |||||||||||
| Camber (1) | 0.5 | -0.0 To 1.0 | |||||||||
| Caster (1) | 4 | 2 To 6 | |||||||||
| Toe-In (2) | 0.03 | -0.08 To 0.15 | |||||||||
| Toe-In (1) | 0.06 | -0.16 To 0.3 | |||||||||
| F350 DRW (2WD) (4) | |||||||||||
| Camber (1) | 0.5 | -0.0 To 1.0 | |||||||||
| Caster (1) | 2.75 | 1.0 To 4.5 | |||||||||
| Toe-In (2) | 0.03 | -0.08 To 0.15 | |||||||||
| Toe-In (1) | 0.06 | -0.16 To 0.3 | |||||||||
| F350 (4WD) | |||||||||||
| Camber (1) | 0.0 | -0.5 To 0.5 | |||||||||
| Caster (1) | 3.38 | 2 To 4.75 | |||||||||
| Toe-In (2) | 0.03 | -0.08 To 0.15 | |||||||||
| Toe-In (1) | 0.06 | -0.16 To 0.3 | |||||||||
| F-Super Duty | |||||||||||
| Camber (1) | 0.0 | -0.5 To 0.5 | |||||||||
| Caster (1) | 3.5 | 2 To 5 | |||||||||
| Toe-In (2) | 0.03 | -0.08 To 0.15 | |||||||||
| Toe-In (1) | 0.06 | -0.16 To 0.3 | |||||||||
|
|||||||||||
