1990 Ford Probe V6-182 3.0LFACTORY OEM SERVICE PROCEDURE
Data Link Connector: Locations
FUEL INJECTORS: The fuel injectors are mounted in the lower intake manifold.
FUEL PRESSURE REGULATOR: The fuel pressure regulator is attached to the fuel supply manifold.
FUEL FILTER: RH fender apron in the engine compartment.
FUEL PUMP: The fuel pump is mounted on the fuel sender assembly inside of the fuel tank.
INERTIA SWITCH: The inertia switch is located behind LH interior liftgate area trim panel.
VIP SELF-TEST CONNECTOR: RH side of dash, near wiper motor.
FUEL PRESSURE REGULATOR: The fuel pressure regulator is attached to the fuel supply manifold.
FUEL FILTER: RH fender apron in the engine compartment.
FUEL PUMP: The fuel pump is mounted on the fuel sender assembly inside of the fuel tank.
Inertia Switch:
INERTIA SWITCH: The inertia switch is located behind LH interior liftgate area trim panel.
VIP SELF-TEST CONNECTOR: RH side of dash, near wiper motor.
